Jagged Type. An interlocked series of Vinyl Sheet Pilings that has no specific form. These types of sheet piles resemble a zig-zag and are used as sealing screens and are typically used as containment barriers for rivers, banks, and shallow trenches.
If you need pilings for bulkheads, seawalls, or cutoff walls, and are looking for an alternative to steel sheet piling, you should consider Vinyl Sheet piles.
These are also known as Synthetic Sheet Piling, Plastic Sheet Piles, and PVC Sheet Piles, they are superior to concrete and wood, eco-friendly, highly corrosion-resistant, and exceptionally durable.
SPECIFICATIONS
| Section | Width | Height | Thickness | Cross Section Area | Section Modulus | Moment of Inertia | Allowable Moment | Ultimate Moment | Ultimate Stiffness | Impact Strength Charpy Test | Weight | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| (W) | (H) | (T) | Per Pile | Per Wall | ||||||||
| in | in | in | in2 | in3/ft | in4/ft | ft-kips/ft | ft-kips/ft | ibf-in2 x106/ft | ft-lbs/ft2 | lb/ft | lb/ft2 | |
| mm | mm | mm | cm2 | cm3/m | cm4/m | kNm/m | kNm/m | kNm2/m | kJ/m2 | kg/m | kg/m2 | |
| ESC-GW600-5.5 | 23.9 | 3.5 | 0.22 | 6.4 | 1.6 | 2.8 | 0.43 | 0.86 | 1.1 | ≥ 14.3 | 3.97 | 1.99 |
| 608 | 88 | 5.5 | 41.1 | 87 | 385 | 1.9 | 3.8 | 9.9 | ≥ 30 | 5.9 | 9.7 | |
| ESC-GW600-6.0 | 23.9 | 3.5 | 0.24 | 6.9 | 1.7 | 3.1 | 0.46 | 0.93 | 1.2 | ≥ 14.3 | 4.3 | 2.16 |
| 608 | 88.5 | 6 | 44.5 | 94 | 417 | 2.1 | 4.1 | 10.8 | ≥ 30 | 6.4 | 10.5 | |
